17) Adjusting the Height of Needle Plate Support Cover 38
18) Adjusting the Height of Slider 38
19) Adjusting the Upper Under stroke of Feed Plate 39
20) Adjusting the X-Guide Bracket 39
21) Adjusting the Under Feed Plate 40
22) Adjusting the Tension of X-Timing Belt 40
23) Setting the X-Y Origin 41
24) Adjusting the Position of Plastic Blank 42
25) SPS/B(A)-1811(2211)-HS-20 Air System Circuit Diagram 43
7. Cause of Break-Down and Troubleshooting 44
8. SPS/B(A)-1811(2211)-HS-21 46
1) Specification 46
2) Adjusting the Initial Position of Two-Step Stroke Air Cynlinder 46
3) Adjusting the Middle Stop Position of Upper Feed Plate 46
4) Adjusting the Speed for Ascension and Acent of Upper Feed Plate 47
5) How to Use the Pedal Switch 47
6) SPS/B(A)-1811(2211)-HS-21 Air System Circuit Diagram 48
9. SPS/B(A)-1811(2211)-HS-22 49
1) Specification 49
2) Adjusting the Angle of Upper Feed Plate(Both Right and Left) 49
3) Adjusting the Initial Position of Air Cyliner 49
4) Adjusting the Middle Stop Position of the Left Upper Feed Plate 49
5) Adjusting the Speed for Ascension and Descent of Upper Feed Plate 50
6) How to Use the Pedal Switch 50
7) SPS/B(A)-1811(2211)-HS-22 Air System Circuit Diagram 52
10. SPS/B(A)-1811(2211)-GS-20(21, 22, 23) 53
1) Machine Sepecifications 53
2) How to Hook the Upper Thread 53
11. SPS/B(A)-1811(2211)-HP(GP)-
54
1) Specifications 54
2) How to Attach the Needle 55
3) How to Hook the Upper Thread 55
4) How to Hook the Lower Thread 55
5) Adjusting the Spring on the upper Side of the Shuttle 56
6) Adjusting the Moving Knife and the Fixed Knife 56
12. Drawing of Table 57
