51
E. In case of attaching mono lithic feeding plate
ⓐ In case of un-using 2-step stroke.
a. Set the parameter, related to the general sewing (function no.60), to 0.
b. If you fully step on the intermediate pedal ②, the upper feed plate descends to the sewing material.
c. If you step on the left pedal③, the machine starts sewing.
[ Fig. 75 ]
③②① ③②①
ⓑ In case of using 2-step strdce.
a. Set the parameter, related to the general sewing (function no.60) to 1.
b. If you step on the first step of the intermediate pedal ②, the upper feed plate descends to the intermediate
position. (If you step off the pedal ②, the upper feed plate ascends to the initial position).
c. When the intermediate pedal ② is fully stepped, the upper feed plate fully descends to the sewing material.
d. If you step on the left pedal ③, the machine starts sewing.
[ Fig. 76 ]
③②① ③②① ③②①
