Chapter 8: Data Specifications
Linear DC
Voltage (Single Phase) 90 - 264 AC Version
Power Source 110 or 220 Single Phase
Current 10 - 4000A 10 Amp/Step
Voltage 0.1 - 10.0V at 10mV/Step
Power 0.01 - 20kW at 10W/Step
Peak Current 4000A
Peak Voltage 10V
Peak Power 20kW
Weld Period Ranges
weld time (each section)
Squeeze/hold Periods
Ranges (msec)
0-100
0-5
Resolution (steps)
0.1ms
1ms
Current Output Accuracy ±10A
Voltage Output Accuracy ±0.005V
Welder (L x W x H)
15.2” x 11.4” x 15.5”
(38.5 x 28.9 x 39.3cm)
Weight 46.5 lbs. (21.1kg)
