Sunstone Micro Weld Head - dual foot pedal triggering
1. Connect weld head cables to negative and positive terminals on the back of the Linear DC.
2. Connect included Linear DC foot pedal into “Weld Discharge Trigger” DIN connection port
on the back of the welder. *With this option users will not connect the weld head actuation
cable to any of the DIN ports.
3. See micro weld head manual for instructions on micro weld head foot pedal setup. *Micro
weld head foot pedal will control weld head up and down movement and Linear DC foot
pedal will control weld triggering.
Sunstone Hand Attachment
1. Connect hand attachment cables to negative and positive terminals on the back of the
Linear DC.
2. Connect hand attachment actuation cable to “Weld Head Actuation” DIN connection port on
the back of the welder.
Precautions
HANDLING PARTS BEING WELDED
Caution: Pieces that have been welded can be HOT. Always use caution when handling welded
pieces.
ELECTRODE CARE
For best results sand (shape) and clean the electrodes prior to performing welds and after
electrode tip wear; smoother electrodes will provide better results.
EMERGENCY STOP SWITCH
e Linear DC is able to be equipped with an Emergency Stop Switch, the Emergency Stop Switch
will attach to the back of the unit into the “Emergency Stop Switch” port.
e Linear DC comes equipped with an “Emergency Stop Switch Key”. is key connects to the
Emergency Stop Switch port on the back on the unit to bypass the need to have an Emergency
Stop Switch. To purchase an Emergency Stop Switch, call in to Sunstone.
When using the Emergency Stop Switch, please be aware of the following:
