SUNSTONE Linear DC - Chapter 8: Data Specifications 35; Quick Look

4
Quick Look
EMERGENCY STOP
Press to shut off system.
AC POWER
Attach AC power here.
COOLING FANS
Keeps system cool. Do
not block.
WELDER INFO
Welder information is
found here.
 + TERMINALS
Connect weld head or
welding attachments cables
here.
FUSE
20A Fuse.
DIN CONNECTION PORTS
Connect welding
attachment DIN
Connections here.
TOUCH SCREEN INTERFACE
Set all weld parameters here.
POWER BUTTON
Press to power up.
USB PORT
Upload software
updates.
