Chapter 2: Getting Started
Set-up Linear DC
WHAT IS IN THE BOX
Carefully open the welder package. Remove and place the contents on a clear and clean
workbench.
Inside the box:
• Linear DC Welding Unit
• Power Cable
• Safety Manual
• Quick Start Guide
SPACE REQUIREMENTS
e Linear DC has a 15.2”x11.4” footprint. Be sure to provide enough space to connect a weld head
or welding hand attachment and roughly a 2-4” space on the backside of the unit to connect
power and weld attachment cables.
SETUP BACK PANEL CONNECTIONS
Positive (+) Terminal
Connect one of the cables from weld head or welding hand attachment to the positive terminal
with the included ¼”-20 screw.
Caution: Terminal and/or cable can become HOT during welding.
Negative (-) Terminal
Connect the other cable from weld head or welding hand attachment to the negative terminal with
the included ¼”-20 screw.
Caution: Terminal and/or cable can become HOT during welding.
AC Inlet
is unit can accept a 50-60Hz AC signal from 90VAC to 250VAC. Use the supplied cable to
connect to the power inlet. Plug the female end of the provided power cable into the back of the
unit. en plug the male end of the power cable into AC power.
