Model SUNSYNK-3.6K-SG02LP1
Battery Input Data
Battery Type Lead-acid or Lithium-ion
Battery Voltage Range 40~60V
Max. Charging Current 90A
Max. Discharging Current 90A
PV String Input Data
Max. DC Input Power 7000W
Voc Max. 500V
MPPT Range 150~425V
Full Load DC Voltage Range 300~425V
Start-up Voltage 125V
PV Input Current 13A+13A
No. of MPPT Trackers 2
No. of Strings Per MPPT Tracker 1+1
AC Output Data
Rated AC Output and UPS Power 3600W
Max. AC Power 3960W
Peak Power (off-gri 2 times of rated power, 10 S
AC Output Rated Current 16.4A
Max AC Output Current 18A
Max Continuous AC Passthrough 35A
Power Factor 0.8 leading to 0.8 lagging
Output Frequency and Voltage 50/60Hz; 220/230/240Vac (single phase)
Current Harmonic Distortion THD<3% (Linear load<1.5%)
Efficiency
Max. Efficiency 97.60%
Euro Efficiency 96.50%
Protection
Integrated
PV Input Lightning Protection, Anti-islanding Protection, PV String
Input Reverse Polarity Protection, Insulation Resistor Detection,
Residual Current Monitoring Unit, Output Over Current Protection,
Output Shorted Protection, Output Over Voltage Protection
Certifications and Standards
Grid Regulation
VDE 0126, AS4777, NRS2017, G98, G99, IEC61683, IEC62116,
IEC61727,
RD1699:2011, XP C15-712-3:2019-05
Safety Regulation IEC62109-1, IEC62109-2
EMC EN61000-6-1, EN61000-6-3
General Data
Operating Temperature Range -25~60°C, >45°C Derating
Cooling Natural Cooling
Noise (dB) <30
Communication with BMS RS485; CAN
Weight 30kg
Size (Length x Width x Height) 233 x 445 x 708 mm
Protection Degree IP65
Warranty 5 years
Page | 12 Hybrid Inverter | Installer Manual
