SunSynk SUNSYNK-5K-SG01LP1 Installer Manual

1. Inverter Indicators 7. DRMs Port 13. Grid
2. LCD Display 8. Parallel Port 14. Power On/Off Button
3. Function Buttons 9. Function Port 15. DC Switch
4. Battery Input Connectors 10. RS 485 Port 16. PV Input with Two MPPT
5. BMS 485 Port 11. Generator Input 17. Battery
6. BMS CAN Port 12. Load 18. Temperature Sensor
19. Wi-Fi Interface 20. Fan (just for some versions)
1
2
5
9
11
12
13
15
16
19
20
18
17
14
7
10
6
3
4
8
ON
1 2
Page | 8 Hybrid Inverter | Installer Manual

SunSynk SUNSYNK-5K-SG01LP1 Specifications

General

Brand	SunSynk
Model	SUNSYNK-5K-SG01LP1
Category	Inverter
Language	English
