SINGLE PHASE HI 3.6/5kW | User Manual75
Fault
Information
Instruction
Fault
Information
Instruction
F01 DC_Inversed_Failure F33 AC_OverCurr_Fault
F02 DC_Insulation_Failure F34 AC_Overload_Fault
F03 GFDI_Failure F35 AC_NoUtility_Fault
F04 GFDI_Ground_Failure F36 AC_GridPhaseSeque_Fault
F05 EEPROM_Read_Failure F37 AC_Volt_Unbalance_Fault
F06 EEPROM_Write_Failure F38 AC_Curr_Unbalance_Fault
F07 GFDI_Fuse_Failure F39 INT_AC_OverCurr_Fault
F08 GFDI_Relay_Failure F40 INT_DC_OverCurr_Fault
F09 IGBT_Failure F41 AC_WU_OverVolt_Fault
F10 AuxPowerBoard_Failure F42 AC_WU_UnderVolt_Fault
F11 AC_MainContactor_Failure F43 AC_VW_OverVolt_Fault
F12 AC_SlaveContactor_Failure F44 AC_VW_UnderVolt_Fault
F13 Working_Mode_change F45 AC_UV_OverVolt_Fault
F14 DC_OverCurr_Failure F46 AC_UV_UnderVolt_Fault
F15 AC_OverCurr_Failure F47 AC_OverFreq_Fault
F16 GFCI_Failure F48 AC_UnderFreq_Fault
F17 Tz_COM_OC_Fault F49 AC_U_GridCurr_DcHigh_Fault
F18 Tz_Ac_OverCurr_Fault F50 AC_V_GridCurr_DcHigh_Fault
F19 Tz_Integ_Fault F51 AC_W_GridCurr_DcHigh_Fault
F20 Tz_Dc_OverCurr_Fault F52 AC_A_InductCurr_DcHigh_Fault
F21 Tz_GFDI_OC_Fault F53 AC_B_InductCurr_DcHigh_Fault
F22 Tz_EmergStop_Fault F54 AC_C_InductCurr_DcHigh_Fault
F23 Tz_GFCI_OC_Fault F55 DC_VoltHigh_Fault
F24 DC_Insulation_Fault F56 DC_VoltLow_Fault
F25 DC_Feedback_Fault F57 AC_BackFeed_Fault
F26 BusUnbalance_Fault F58 AC_U_GridCurr_High_Fault
F27 DC_Insulation_ISO_Fault F59 AC_V_GridCurr_High_Fault
F28 DCIOver_M1_Fault F60 AC_W_GridCurr_High_Fault
F29 AC_AirSwitch_Fault F61 AC_A_InductCurr_High_Fault
F30 AC_MainContactor_Fault F62 AC_B_InductCurr_High_Fault
F31 AC_SlaveContactor_Fault F63 ARC_Fault
F32 DCIOver_M2_FaulT F64 Heatsink_HighTemp_Fault
PLEASE NOTE
The Single-Phase Hybrid Inverter is designed for grid-connected operation.
The inverters meet the main standards concerning safety and electromagnetic compatibility. Be-
fore leaving the factory, all inverters undergo rigorous testing to ensure the inverter can operate
reliably, as presented in Chapter 3, ‘Technical Specications’.
If you need further help please refer to the Sunsynk website where you will nd training videos and frequent-
ly asked questions www.sunsynk.com.
