7.2.2 Oil
Oil use for SWDM240B can be found in the table 8-2-2.
Table 8-2-2 Oil capacity and type
No.
Components or
system
Capacity
（L）
Oil type
Remark
1
Fuel tank
490
0# diesel（4°above）
-10# diesel
（
-5°-4°
）
The diesel for lower environment temperature can be
selected for real condition.
2
Engine oil capacity
25
CI-4
15W-40
1.Viscosity: 15W-40
2.Choose oil of suitable viscosity according to
environment temperature
3. The filling capacity depends on the scale of engine
oil dipstick(between LOW and HIGH)
3
Engine coolant
11.1
Antifreeze ： 50% Ethylene
glycol or Propylene glycol
+50% purified water
1. Don’t mix antifreeze of different types.
2. The filling capacity of antifreeze is up to the upper
sight glass of radiator or the filler.
4
Radiator water tank
11
5
Hydraulic oil tank
154
Forth, Total or International
standard 68
＃
antiwear
hydraulic oil
Cylinder (luffing, mast, crowd, track extension &
retraction etc.), fill up to the upper scale line of tank
level gauge; Fill up to the lower scale line when the
cylinder extend and retract fully).
6
Swing reduction gearbox
5.5
Industrial gear oil 220
In the reduction gearbox
7
Travel reduction gearbox
2×7.5
Industrial gear oil 220
8
Rotary head housing
35-40
Industrial gear oil 220
9
Rotary head reduction
gearbox
2×7
Industrial gear oil 220
10
Main winch reduction
gearbox
6
Industrial gear oil 220
11
Auxiliary winch
reduction gearbox
3
Industrial gear oil 220
12
Swing gear ring
30kg
Lithium base grease
13
Left & right crawler
tension cylinder
As required
Lithium base grease
Adjust track tension to specified requirements.
14
Carbamide tank
56
Carbamide
32.5% high cleaning carbamide + 67.5%
deionized water
Note
：
