Overhaul Manual
O-360 and IO-360 Series Engines
Installation of Intake Pipes
(1) Slide the intake flange (10, Figure 72-
00-09.29) onto the intake elbow (5).
Allow the flanged end of the elbow to
seat in the recessed flat side of the
intake flange.
(2) Install the rubber hose coupler (30) onto
other end of the elbow along with 2
clamps (35).
(3) Place the bolts (25) with the appropriate
lock washer (20) and flat washer (15)
through the holes in the intake flange.
Install the gasket (1) over the bolts.
Refer to Figure 72-00-09.29.
(4) Attach the elbow assembly to the engine
with the hose connection to sump and
the flange coupling to the intake port of
the cylinder head. Refer to Figure 72-
00-09.30.
(5) Slide the hose coupler over the intake
extension in the sump. Center the hose
coupler over the joint and tighten the
bolts (25) into the cylinder head until
snug.
(6) Ensure that the flange end of the intake
elbow fits completely in the recess in the
aluminum hold down flange (10). This
must lay flat against the cylinder port.
Torque the bolts (25) 96 to 108 in-lbs.
(7) Position the clamps (35) over the hose
coupler (20) to secure each side of the
connection. Tighten to 10 in-lbs.
38
© March 2005 Superior Air Parts Inc.
72-00-09
Engine Assembly
To Next Page
