Superior IO-360 SERIES Overhaul Manual

Overhaul Manual
O-360 and IO-360 Series Engines
DISASSEMBLY
General
This section contains disassembly procedures.
When necessary, disassembly illustrations are
also provided. All item number references in the
text are specific to this manual and the figures
cited.
Disassembly Materials
The materials required for disassembly are listed
in Table 72-00-06.1.
NOTE:
Equivalent substitutes may be used.
Table 72-00-06.1 • Disassembly Materials
Description Source
Penetrating Oil Commercially Available
Parts for Discard
Parts to be discarded are listed in Table 72-00-06.2.
Table 72-00-06.2 • Discard Parts
Nomenclature
All Engine Oil, Air and Fuel Hoses
Gaskets, Oil Seals, and O-Rings
Bearing Inserts (Connecting Rod and Crankshaft)
Piston Rings and Piston Pins
Stressed Bolts and Fasteners
Intake and Exhaust Valves, Valve Guides and Valve Keepers
Crankshaft Gear Attaching Bolt
Connecting Rod Nuts and Bolts
All Lockwashers, Circlips, Retaining Rings, Locktabs and Locknuts
Counterweight Bushings in Crankshaft and Counterweights (if applicable)
Counterweight Washers (if applicable)
Vermatherm (Oil Temperature Bypass Valve)
Special Tools and Equipment
Special tools and equipment required for
disassembly are listed in Table 72-00-06.3.
NOTE:
Standard reciprocating engine aviation
shop tools and equipment are used
unless otherwise specified.
1
© March 2005 Superior Air Parts Inc.
72-00-06
Engine Disassembly
