Overhaul Manual
O-360 and IO-360 Series Engines
NOTE:
Use care to not force debris into drilled
areas, passages, ports, or threaded
receptacles.
WARNING
: SOLVENT IS TOXIC. USE IN
WELL-VENTILATED AREA. PREVENT EYE
AND SKIN CONTACT AND DO NOT
BREATHE VAPORS. IN CASE OF EYE
CONTACT, FLUSH WITH WATER FOR 15
MINUTES AND SEEK MEDICAL ATTENTION.
IN CASE OF SKIN CONTACT, WASH WITH
SOAP AND WATER.
Fuel Injector and Primer Nozzles
Remove the nozzle. Submerge in a cleaning
solvent such as Stoddard Solvent or MEK or
equivalent. Allow soaking for several hours.
Remove from solvent and dry with dry and clean
compressed air. Ultra-sound cleaning methods
may also be used.
WARNING
: SOLVENT IS TOXIC. USE IN
WELL-VENTILATED AREA. PREVENT EYE
AND SKIN CONTACT AND DO NOT
BREATHE VAPORS. IN CASE OF EYE
CONTACT, FLUSH WITH WATER FOR 15
MINUTES AND SEEK MEDICAL ATTENTION.
IN CASE OF SKIN CONTACT, WASH WITH
SOAP AND WATER.
WARNING
: WHEN YOU USE COMPRESSED
AIR TO CLEAN OR DRY PARTS, MAKE SURE
THAT THE PRESSURE IS NOT MORE THAN
30 PSI. DO NOT DIRECT THE AIRSTREAM
AT PERSONNEL OR LIGHT OBJECTS. PUT
ON GOGGLES OR A FACE SHIELD TO
PROTECT YOUR EYES. IF YOU GET AN EYE
INJURY, GET MEDICAL ATTENTION.
CAUTION
: DO NOT USE A SHARP TOOL TO
CLEAN OR DISASSEMBLE FUEL OR AIR
BLEED NOZZLES.
NOTE: Under normal conditions, the shield
and screen are NOT removed from the
nozzle assembly. If removal is
necessary, both must be thoroughly
cleaned prior to reassembly. The
shield must have a tight fit on the
body.
Screens and Filters
A. Fuel system filters
(1) Fuel screens may be soaked and
rinsed in clean solvent and dried
with compressed air.
B. Oil system filters
(1) Oil screens may be soaked and
rinsed in clean solvent and dried
with compressed air.
(2) Disposable external oil filter
elements are not cleaned.
C. Air induction system filters
(1) Foam air filters may be rinsed in
clean solvent then washed with mild
detergent and water and reinstalled.
Paper air filter elements are not cleaned
WARNING
: SOLVENT IS TOXIC. USE IN
WELL-VENTILATED AREA. PREVENT EYE
AND SKIN CONTACT AND DO NOT
BREATHE VAPORS. IN CASE OF EYE
CONTACT, FLUSH WITH WATER FOR 15
MINUTES AND SEEK MEDICAL ATTENTION.
IN CASE OF SKIN CONTACT, WASH WITH
SOAP AND WATER.
WARNING
: WHEN YOU USE COMPRESSED
AIR TO CLEAN OR DRY PARTS, MAKE SURE
THAT THE PRESSURE IS NOT MORE THAN
30 PSI. DO NOT DIRECT THE AIRSTREAM
AT PERSONNEL OR LIGHT OBJECTS. PUT
ON GOGGLES OR A FACE SHIELD TO
PROTECT YOUR EYES. IF YOU GET AN EYE
INJURY, GET MEDICAL ATTENTION.
Accessories
Refer to the various manufacturers’ manuals for
information regarding the cleaning of these
components.
3
© March 2005 Superior Air Parts Inc.
72-00-07
Cleaning
