Superior IO-360 SERIES Overhaul Manual

Overhaul Manual
O-360 and IO-360 Series Engines
ENGINE ASSEMBLY
General
This section has the procedures and illustrations
necessary to assemble the Vantage O-360 and
IO-360 series engine.
Fits, Clearances and Torque Values
Fits, clearances and torque values to be
established during repair or assembly are listed
in the applicable paragraph so that the unit can
be assembled without reference to another
section of the manual.
NOTE:
Limits followed by a letter “T” indicate
“tight”, i.e., interference fit. An
example is the valve guide in the
cylinder head. Where no “T” exists,
the fit is a clearance dimension.
Materials Required for Assembly
Materials required for assembly are listed in
Table 72-00-09.1 below.
NOTE:
Equivalent substitutes may be used for
listed items.
Table 72-00-09.1 • Assembly Materials
Material Source
Acetone or Methyl Ethyl Ketone (MEK) Commercially Available
Assembly Grease – Lubriplate
TM
No. 105 Commercially Available
Cleaning Solvent Commercially Available
Copper Based Anti-seize, Fel-Pro
TM
C5-A Commercially Available
Fuelube
TM
Commercially Available
Loctite
TM
241, P/N 27183 Commercially Available
Loctite
TM
No. 2 Gasket Sealant P/N 30514 Commercially Available
Oil, Aviation Grade (Mineral, Non-detergent) Commercially Available
Permatex
TM
, P/N 27100 Commercially Available
Pre-Lube Mixture – approx. 15% STP
TM
and 85% Aviation Mineral Oil Mixed Locally
RTV
TM
102 Silicon Sealant Commercially Available
Safety Wire (0.032 in.) Type 304 Stainless, P/N MS20995 C32 Commercially Available
Safety Wire (0.041 in.) Type 304 Stainless, P/N MS20995 C41 Commercially Available
Silk Thread #50 (100% Silk) Commercially Available
STP
TM
High Viscosity Oil Treatment Commercially Available
Titeseal
TM
No. 2 Gasket and Joint Compound P/N T2-01 Commercially Available
Special Tools and Equipment
Special tools and equipment required for
assembly are listed in Table 72-00-09.2 below.
NOTE:
Equivalent substitutes may be used for
listed items.
NOTE: Standard reciprocating engine aviation
shop tools and equipment are used,
unless otherwise specified.
NOTE:
Unless otherwise specified, all gaskets
are installed dry.
1
© March 2005 Superior Air Parts Inc.
72-00-09
Engine Assembly
