Superior IO-360 SERIES Overhaul Manual

Overhaul Manual
O-360 and IO-360 Series Engines
WARNING
: ADHESIVE SEALANT IS TOXIC
AND FLAMMABLE. DO NOT BREATHE
VAPORS. AVOID EYE AND SKIN CONTACT.
USE PROTECTIVE GEAR. IN CASE OF EYE
CONTACT, FLUSH WITH WATER FOR 15
MINUTES AND SEEK MEDICAL ATTENTION.
IN CASE OF SKIN CONTACT, WASH WITH
SOAP AND WATER.
(8) Apply TiteSeal™ thread sealant or
equivalent to the threads of 90º elbow
fitting (10) and install in the right
crankcase half, forward of No.1 cylinder.
Refer to Figure 72-00-09.34.
(9) Position fittings per Figure 72-00-09.34
and install the propeller governor oil
hose (1). Torque the oil hose (1) nuts to
35 in-lbs.
Installation of Propeller Governor Cover
Plate
(1) This instruction applies to all engine
models not requiring a prop governor.
(2) For the engine models where no
propeller governor is used, install cover
(65, Figure 72-00-09.33), gasket (60),
washer (30), and lockwasher (25).
Torque the 5/16 in. nuts (30) to 200 in-
lbs.
Installation of Oil Filter Adapter (if furnished)
(1) Install the Vernatherm valve (45) with
the aluminum gasket and torque to 300
in-lbs. Install safety wire (0.032 in.) from
the Vernatherm to the adapter.
(2) Install the oil filter adapter (10, Figure
72-00-09.35) to the accessory housing
with the gasket (5), washers (15), lock
washers (20), 1 nut (25), and 3 screws
(30). Torque to 96-108 in-lbs.
WARNING
: PUT ON SAFETY GOGGLES
WHEN INSTALLING OR REMOVING SAFETY
WIRE.
Installation of Spin-On Oil Filter
(1) Apply light coat of Dow Corning #4
lubricant or equivalent to the rubber seal
at base of the oil filter (40, 72-00-09.35)
and lightly lubricate the filter threads
then install to the adapter (10) and
torque to 192-216 in-lbs. Reference
SVIMM01, Maintenance Manual. Install
safety wire (0.032 in.) from the oil filter
to the adapter.
WARNING
: PUT ON SAFETY GOGGLES
WHEN INSTALLING OR REMOVING SAFETY
WIRE.
WARNING: LUBRICANTS ARE TOXIC AND
FLAMMABLE. DO NOT BREATHE VAPORS.
BEFORE YOU USE, READ THE MATERIAL
SAFETY DATA SHEET (MSDS) FROM THE
MANUFACTURER OR SUPPLIER. USE IN A
WELL-VENTILATED AREA FREE FROM
SPARKS. WEAR PROTECTIVE GEAR. IN
CASE OF EYE CONTACT, FLUSH WITH
WATER FOR 15 MINUTES AND SEEK
MEDICAL ATTENTION. IN CASE OF SKIN
CONTACT, WASH WITH SOAP AND WATER.
48
© March 2005 Superior Air Parts Inc.
72-00-09
Engine Assembly
