Overhaul Manual
O-360 and IO-360 Series Engines
NOTE:
While rotating the magneto shaft
backwards with alignment pin in hole, if
the shaft stops turning due to internal
interference against the alignment pin
prior to pin seating, pull pin out just far
enough to allow the shaft to continue to
rotate. Re-insert the pin and continue
rotation until the pin seats as previously
described. This procedure locates the
magneto at the No.1 cylinder firing
position.
(8) Repeat for the 2nd magneto’s
alignment.
(9) Bring the engine to the compression
stroke on the No. 1 cylinder.
(10) Rotate engine to approx. 25º before top
dead center using a timing indicator
installed in a spark plug hole of the No.
1 cylinder or equivalent method.
WARNING
: LUBRICANTS ARE TOXIC AND
FLAMMABLE. DO NOT BREATHE VAPORS.
BEFORE YOU USE, READ THE MATERIAL
SAFETY DATA SHEET (MSDS) FROM THE
MANUFACTURER OR SUPPLIER. USE IN A
WELL VENTILATED AREA FREE FROM
SPARKS. WEAR PROTECTIVE GEAR. IN
CASE OF EYE CONTACT, FLUSH WITH
WATER FOR 15 MINUTES AND SEEK
MEDICAL ATTENTION. IN CASE OF SKIN
CONTACT, WASH WITH SOAP AND WATER.
(11) Apply pre-lube oil to the idler gear teeth
and magneto drive gear teeth (35) and
apply light coat of Dow Corning™ #4 or
Fuelube™ to the magneto gasket (10).
Install each magneto with the clamp
(20), lock washers (25), and nut (30).
Tighten moderately.
NOTE:
Magnetos must be able to move for
final timing. This will be accomplished
later with the engine horizontal,
disconnected from nose stand, and with
the ring gear and starter installed.
WARNING
: DO NOT ROTATE ENGINE OR
CRANKSHAFT BEFORE REMOVAL OF
TIMING LOCATOR PINS.
(12) Remove the timing locator pins from the
magnetos (15) and install the harness.
Ensure correct harness locations. Align
the harness cover caps properly.
Secure with the screws removed from
the cap removal.
Starter Installation
(1) Verify the starter part number.
(2) Install the starter IAW the starter
manufacturer’s installation instructions.
Tighten the bolt and nuts to 200 in-lbs.
Alternator Installation (if furnished)
(1) Verify the alternator part number is
correct.
(2) Install pulley, as required, to alternator
IAW manufacturer’s installation
instructions.
(3) Attach mounting bracket (55, Figure 72-
00-09.43) to engine with bolts (60) and
lock plate (50) and tighten until snug
(finger tight).
(4) Attach alternator to mounting bracket
(55) using drilled shank bolts (25, 30)
with shim washers (35) and hardware as
required for alternator pulley/belt
alignment to starter ring gear assembly.
(5) Attach strut support (80) to alternator
bracket in forward location using bolt
(25).
(6) Install adjusting link (65) to crankcase
and alternator with drilled head bolts
(75, 10). Use single washer (70) at the
crankcase attach point and two (2)
washers (5) at slotted alternator attach
point for strength.
NOTE:
Leave all attach hardware snug or
finger tight as required to allow for
alignment and belt tension adjustment.
(7) Install alternator belt (not shown) to
starter ring gear assembly and install
starter ring gear assembly to crankshaft
flange. Reference SVMM01,
Maintenance Manual. A “slave” bolt
may be used to temporarily hold starter
57
© March 2005 Superior Air Parts Inc.
72-00-09
Engine Assembly
To Next Page
