Overhaul Manual
O-360 and IO-360 Series Engines
(3) Remove the bearing inserts (5, 10,
Figure 72-00-09.2), lifter bodies (20),
and camshaft. Remove and discard o-
ring seals (10, 75).
NOTE:
Place each lifter body in its proper
location in a cleaning basket. The
lifter bodies must be assembled in
their original locations if reused.
(4) Remove all threaded plugs and discard
oil seals.
Crankshaft Disassembly
(1) With the crankshaft firmly supported at
the front and rear main bearing journals
(or secured on a nose stand), remove
rod nuts (15, Figure 72-00-09.6).
Remove the rods (5) by tapping on the
rod bolts (10) with a soft hammer.
Discard the connecting rod bearing (1),
bolts (10), and nuts (15).
NOTE:
Maintain each cap and rod as an
assembly. Rods and caps are not
interchangeable.
(2) To remove the crankshaft gear (5,
Figure 72-00-09.3), flatten the lockplate
(10) and remove screw (15). Tap the
gear lightly with a soft mallet or brass
drift. Remove the crankshaft oil seal
and discard.
6
© March 2005 Superior Air Parts Inc.
72-00-06
Engine Disassembly
