Superior IO-360 SERIES Overhaul Manual

Overhaul Manual
O-360 and IO-360 Series Engines
Accessory Housing
Initially inspect accessory housing as illustrated
in Figure 72-00-08.2. Remove all accessories
(magnetos, pumps, valves, etc.) for separate
inspection.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Obvious
excessive
damage
Reject
Visually inspect accessory housing.
(1) Inspect accessory housing flange and
drive pad surfaces.
Deep scratches Reject
Minor scratches
Blend/hand
polish per
Repair No.2
(2) Inspect accessory case threaded and
drilled areas and passages.
Worn or
mutilated,
distorted, galled
Reject
Slight nicks or
burrs
Blend/hand
polish per
Repair No.1
Obstructions or
plugs
See Cleaning
section of this
manual
Crankcase Assembly
Perform initial inspection of crankcase assembly
per Figure 72-00-08.3.
Obvious
excessive
damage or
wear
Reject
(1) Inspect all crankcase bearing bores
and journals, saddle supports, support
webs, tang slots, and flange surfaces.
Deep scratches Reject
Fretting, heavy
wear, flat spots
Reject
Minor scratches
Blend/hand
polish per
Repair No.2
Misalignment of
mating surfaces
Reject
Out of round
conditions on
journals
Reject
(2) Inspect crankcase threaded studs and
drilled holes and passages.
Worn,
mutilated,
distorted, or
galled
Reject/See
Repair No. 1
Slight nicks or
burrs
Blend/hand
polish per
Repair No.1
NOTE:
Surfaces may be checked visually and
by feel for roughness, flaking, and
pitting of races and for scoring on the
outside of the bearing races. Shafts,
pins, etc., may be checked using vee
blocks and dial indicators.
NOTE:
Aluminum surfaces can withstand
considerable scratching and light
scoring without harming the engine
integrity or performance provided
these problems fall within the limits set
forth in the Fits and Clearances
section of this manual.
NOTE:
Fretting on the saddle supports in the
crankcase has a frosted appearance
and tiny pit holes. This usually
indicates a change in the size of the
bearing saddles that can be sufficient
to cause an excessively tight
crankshaft bearing fit.
3
© March 2005 Superior Air Parts Inc.
72-00-08
Inspection and Check
