Chassis SC743 User's Manual
30
Note: Enterprise level hard disk drives are recommended for use in Supermicro chassis and
servers. For information on recommended HDDs, visit the Supermicro website at http://www.
supermicro.com/products/nfo/les/storage/SBB-HDDCompList.pdf
Installing 2.5" Drive into the Converter Tray
The 2.5" drives feature a toolless installation method.
1. Fit one side of the drive against the release lever.
2. Press the other side of the drive down until it clicks into place.
Figure 3-3. Mounting a 2.5" Drive into a Carrier
Removing 2.5" Drive from the Converter Tray
1. Press down on the release tab untils the drive pops up from the tray.
2. Remove the 2.5" drive from the tray.
1
Figure 3-4. Removing a 2.5" Drive from the Carrier
