SC826 JBOD Chassis Manual
3-4
3-4 Drive Carrier LEDs
The SC826 JBOD chassis uses SAS or SATA drives. Each drive carrier has
two LED indicators on the front, one blue and red. The LEDs function as follows:
Blue Drive Carrier LED Indicator
Color Status Description
Blue Steady on Indicates a SAS drive
Blue O Indicates a SATA drive
Blue Blinking Drive is actively being accessed
Red Drive Carrier LED Indicator
Color Status Description
Red Steady on Drive failure
Red Blinking RAID activity
When the red LED is blinking, it indicates that the system is either building,
initializing or rebuilding RAID.
3-5 Power Supply LEDs
On the rear of the power supply module, an LED displays the status.
• Solid Green: When illuminated, indicates that the power supply is on.
• Solid Amber: When illuminated, indicates the power supply is plugged in and
• Blinking Amber: When blinking, this system power supply temperature has
reached 63C. The system will automatically power-down when the power supply
temperature reaches 70C and restart when the power supply temperature goes
below 60C.
