B-1
Appendix B
BPN-SAS3-826EL Backplane Specications
B-1 Overview of the SAS3-826EL1/EL2 Backplanes
This appendix provides details about the backplanes used in the SC826 JBOD
chassis.
Chassis Model Backplane Feature
SC826BE1C-R741JBOD BPN-SAS3-826EL1 Single SAS expander
SC826BE2C-R741JBOD BPN-SAS3-826EL2 Dual SAS expanders
B-2 Safety Guidelines
ESD Safety
Electrostatic Discharge (ESD) can damage electronic com ponents. To prevent
damage to your system, it is important to handle it very carefully. The following
• Use a grounded wrist strap designed to prevent static discharge.
• Touch a grounded metal object before removing a component from the antistatic
bag.
• Handle the backplane and daughter cards by their edges only; do not touch its
components, peripheral chips, memory modules or gold contacts.
• When handling chips or modules, avoid touching their pins.
• Put the card and peripherals back into their antistatic bags when not in use.
General Safety Guidelines
To avoid personal injury and property damage, carefully follow all the safety steps
listed below when accessing your system or handling the components.
• Always disconnect power cables before installing or removing any components
from the computer, including the backplane.
