4-1
Chapter 4: Chassis Setup and Maintenance
Chapter 4
Chassis Setup and Maintenance
4-1 Overview
This chapter covers the steps required to install components and perform
maintenance on the chassis. The only tool required is a Phillips screwdriver.
Review the warnings and precautions listed in the manual before setting up or
servicing this chassis. These include information in Chapter 2: Warnings for AC
Systems, and the precautions listed in the setup instructions.
Figure 4-1. Chassis Front
Figure 4-2. Chassis Rear
(E2C model shown)
Control Panel
BMC
LAN
SAS
