SC826 JBOD Chassis Manual
4-4
SAS Cables
This drawing shows connectors for SAS cabling. For primary and secondary, the top
two connectors are marked In, and the bottom two connectors are marked In/Out.
Connect two mini-SAS HD cables (SFF-8644) from the head server node host bus
adapter (HBA) card to the top two Primary receptacles marked In. If using the E2C
model (SC826BE2C-R741JBOD) for redundancy, connect two more mini-SAS HD
cables to the top two Secondary receptables also marked In. Cables are described
in Appendix B.
To cascade out, connect cables from the two receptacles marked In/Out to the next
JBOD storage enclosure. (see Figure 4-4 and 4-5)
Figure 4-3. SAS and IPMI Cables
(E2C model shown)
Labeled "In"
on Chassis
{
{
}
}
Labeled "In"
on Chassis
Labeled "In/Out"
on Chassis
Labeled "In/Out"
on Chassis
Primary
Secondary
(E2C only)
IPMI
