Chapter 4: Chassis Setup and Maintenance
HBA
SC826 JBOD
SC826 JBOD
Figure 4-4. Sample Cascading Storage, Single HBA
Cascading Storage
The following diagram shows a server with a single host bus adapter (HBA) and
requires only the primary expander on the backplane. The SC826 JBOD storage

External Mini-SAS HD Cable
Server with Single
Host Bus Adapter (HBA)
