Supermicro CSE-826BE1C-R609JBOD User Manual

SC826 JBOD Chassis Manual
4-6
HBA
SC826 JBOD
SC826 JBOD
Figure 4-5. Sample Cascading Storage, Dual HBAs
HBA
The following diagram shows a server with dual HBAs and requires the primary and
secondary expanders on the backplane. The SC826 JBOD storage enclosure

External Mini-SAS HD Cable
Server with Dual
Host Bus Adapters (HBAs)
