9. PMBus Connector
This connector is designated JPI2C1 and connects the power distributor to the
Power Management Bus (PMBus).
10. Fan Connectors
The fan connectors supply power to the fans and are designated FAN1-FAN10.
11. ATX Power Connector
The ATX power connector is designated JPW1.
Jumpers and LED Indicators
SAS2/SAS3 Jumpers
Jumper Description
JP7
Pins 1-2: Obsolete, do not use
Pins 2-3: User mode (static/DHCP, default)
JP5
Pins 1-2: SAS3 enabled
Pins 2-3: SAS2 enabled and SC847D
Figure 6-2. Jumpers
To enable SAS2 or SAS3 functionality on the I
2
C connectors, set the JP5 jumper
as noted.
