Chapter 1: Introduction
1-5
Quick Reference
Jumpers Description Default Setting
JBT1 CMOS Clear (See Chapter 2)
JFSB1/JFSB2 CPU Frequency Pins 1-2/Pins 1-2(Auto)
JI
2
C1/JI
2
C2 SMB to PCI Slots Open/Open (Disabled)
JP2 (PDSBA-Q+/PDSBA+)ITE IDE Enabled Pins 1-2 (Enabled)
JP3 (PDSBA-Q+/PDSBA+/PDSBA) TPM Enable Pins 1-2 (Enabled)
JPL1 Giga-bit LAN Enable Pins 1-2 (Enabled)
JPUSB1 B/P USB Wake Up Pins 2-3 (Disabled)
JPUSB2 F/P USB Wake Up Pins 2-3 (Disabled)
JPWAKE1 Keyboard/Mouse Wake-Up Pins 1-2 (Enabled)
JWD Watch Dog Timer Out Option Pins 1-2 (Reset)
Connectors Description
Audio Audio Port
CD-In (CD1) Audio CD Input Header
Chassis Intrusion Chassis Intrusion Header
COM1, COM2 COM Port/Serial Port 1 & Port 2 Connectors
DIMM#1A,#2A,#1B,#2B Memory (DIMM) Slots (1 through 4)
Fans 1-3 Fan1: CPU Fan, Fan2/3: Chassis Fan Headers
Floppy Floppy Disk Connector
FP Audio Front Panel Audio Connector (See Chapter 2)
LAN Port Ethernet RJ45 (Gigabit LAN) Connector
IDE#1/IDE#2 IDE Hard Drive #1 & Hard Drive #2 (See Page 1-4)
J40 ATX 24-Pin Power Connector
J41 12V 4-pin Power Connector (required)
JF1 Front Control Panel Header
SATA #0/1/4/5 SATA (#0/1/4/5) Headers
KB/Mouse PS/2 Keyboard/Mouse
LE1 Standby Warning LED Indicator
PWR LED Power LED Indicator
Printer Parallel Printer Port
RAID LED External RAID LED Header (Optional for OEM Only)
Slot 1-Slot 4 PCI 33 MHz (PCI #1-#4) (Note)
Slots 5-7 PCI-E x4 (Slot5), PCI-E x16 (Slot6), PCI-Ex1 (Slot7)
Speaker Speaker Header
USB 1/2 (Back Panel) Universal Serial Ports 1-2
USB 3/4/5/6 (Back Panel) Universal Serial Ports 3-6
USB 7/8/9/10 (Front Panel) USB ports 7/8 (J44), USB 9/10 (J45)
VGA Video/Graphic Connector (See Notes on Page 1-4)
WOL Wake-On-LAN Header
WOR Wake-On-Ring Header
Note: PCI Slot 4 (PCI-33 MHz) is not available on the PDSBA/PDSBE only.
