Chapter 1: Introduction
1-7
• Thermal Monitor 2 (TM2) support
• SMT support (PDSBA-Q+/PDSBA+/PDSBA only)
ACPI Features
• Slow blinking LED for suspend state indicator
• BIOS support for USB keyboard
• Main switch override mechanism
• External modem ring-on
Onboard I/O
• Built in ICH8 SATA Controller, 4 connectors for 4 devices (300MB/S)
• 1 fl oppy port interface (up to 2.88 MB)
• 1 Fast UART 16550 compatible serial port/header
• Intel 82573L Gigabit Ethernet Controller (PCI-E)
• 1 EPP (Enhanced Parallel Port) and ECP (Extended Capabilities Port) with
parallel port supported
• PS/2 mouse and PS/2 keyboard ports
• ITE Controller supports four IDE hard drives (PDSBA-Q+/PDSBA+ only)
• Up to 10 USB (Universal Serial Bus) 2.0 ports for a speed of up to 480Mbps
• Realtek ALC 883 7.1 Channel High Defi nition Audio (HDA) codecs supports 10
DAC Channels
• Built-in GMCH and Onboard VGA Connector (PDSBA-Q+/PDSBA+/PDSBA
only)
Other
• Trusted Platform Module (TPM) support (PDSBA-Q+/PDSBA+/PDSBA only)
• Wake-on-LAN
• Wake-on-Ring (WOR)
• System Bus Clock Frequency Selection (Overclocking) Support (Note)
• Suspend-to-RAM
• Onboard +3V Standby Power Warning LED ("LE1")
• Pb Free
CD Utilities
• BIOS fl ash upgrade utility
• Drivers and software for Intel Q965-Express/G965/P965 chipset utilities
Dimensions
• ATX form factor, 11.6" x 9.6" (294.6 x 243.8 mm)
Note: For SATA RAID confi guration instructions, please refer to the Intel
HostRAID Utility User Guide listed on our website (http://www.supermicro.
com/Product/motherboard).
