NIC1/NIC2 (LAN1/LAN2)
The NIC (Network Interface Control-
ler) LED connection for LAN port 2
is located on pins 9 and 10 of JF1,
and the LED connection for LAN port
1 is on pins 11 and 12. Attach NIC
LED cables to their respective pins to
display network activity. Refer to the

LAN1/LAN2 LED
Pin Denitions (JF1)

9-11 3.3V Standby
10-12 NIC Activity LED
Overheat (OH)/Fan Fail/PWR Fail/
UID LED
Connect an LED cable to pins 7
and 8 of JF1 for Overheat/Fan Fail/
Power Fail and UID LED indications.
The blue LED on pin 7 works as the
front panel UID LED indicator. The
red LED on pin 8 works provides
warnings of overheat, fan failure or
power failure. The red LED takes
precedence over the blue LED by
default. Refer to the table on the right

Reset Button
The Reset Button connection is lo-
cated on pins 3 and 4 of JF1. Attach
it to a hardware reset switch on the
computer case to reset the system.
Refer to the table on the right for pin

Reset Button
Pin Denitions (JF1)

3 Reset
4 Ground
OH/Fan Fail/PWR Fail/Blue UID LED
Pin Denitions (JF1)

7 Blue UID LED
8 OH/Fan Fail/Power Fail Cathode
Power Fail LED
The Power Fail LED connection is
located on pins 5 and 6. Refer to the

Power Fail
Pin Denitions (JF1)

5 3.3V
6 Power Fail
