14
SuperServer 1029P-WTRT User's Manual
Connector Description
SXB2 PCI-E 3.0 x16 Right Riser Card slot supported by CPU2
T-SGPIO3 Serial General Purpose I/O port
USB0/1 Back panel USB 3.0 ports
USB2/3 Back panel USB 3.0 ports
USB4/5 USB 3.0 headers
VGA Back panel VGA port
LED Description Status
LE1  
LE2 Onboard Power LED On: Onboard Power On
LE3 M.2 LED Blinking Green: Device Working
LEDM1 BMC Heartbeat LED Blinking Green: BMC Normal
