SuperServer 1029P-WTRT User's Manual
4-pin BMC External I
2
C Header
A System Management Bus header for IPMI 2.0 is located at JIPMB1. Connect the appropriate
cable here to use the IPMB I
2
C connection on your system. Refer to the table below for pin

External I
2
C Header
Pin Denitions
Pin# Denition
1 Data
2 Ground
3 Clock
4 No Connection
Chassis Intrusion
A Chassis Intrusion header is located at JL1 on the motherboard. Attach the appropriate cable
from the chassis to inform you of a chassis intrusion when the chassis is opened. Refer to

Chassis Intrusion
Pin Denitions
Pin# Denition
1 Intrusion Input
2 Ground
NVMe I
2
C Header
Connector JNVI
2
C1 and JNVI
2
C2 are a management headers for the Supermicro AOC NVMe
PCI-E peripheral cards. Please connect the I
2
C cables to these connectors.
NVMe Slots
Use the four NVMe slots (P1_NVME0, P1_NVEM1, P2_NVEM0, and P2_NVME1) to attach
high-speed PCI-E storage devices.
Power LED/Speaker
On the JD1 header, pins 1-3 are for the power LED and pins 4-7 are for the internal speaker.
If you wish to use an external speaker, connect its cable to pins 1-4.
Speaker Connector
Pin Denitions
Pin Setting Denition
Pins 1-3 Power LED
Pins 4-7 Speaker
Micro SD Card
There is one Micro SD memory card slot located at JSDCARD1 on the motherboard.
