26
Chapter 3: Maintenance and Component Installation
A
B
D
Allow Notch D to
latch on to CPU
Allow Notch B to
latch on to CPU
Allow Notch C to
latch on to CPU
C
A
A
C
C
D
D
Pin 1
Align CPU Pin 1
Align Notch C of the CPU
and Notch C of the Processor Clip
Align Notch D of the CPU
and Notch D of the Processor Clip
CPU (Upside Down)
w/CPU LGA Lands up
CPU/Heatsink Package
(Upside Down)
B
B
Align Notch B of the CPU
and Notch B of the Processor Clip
Processor Package Assembly for the -F Model Processors
(with CPU mounted on the Processor Clip)
