SuperServer 1029P-WTRT User's Manual
HDD LED
The HDD LED connection is located on pins 13 and 14 of JF1. Attach a cable to pin 14 to

HDD LED
Pin Denitions (JF1)
Pins Denition
13 3.3V Stdby
14 HDD Active
Power LED
The Power LED connection is located on pins 15 and 16 of JF1. Refer to the table below

Power LED
Pin Denitions (JF1)
Pins Denition
15 3.3V
16 PWR LED
NMI Button
The non-maskable interrupt (NMI) button header is located on pins 19 and 20 of JF1. Refer

NMI Button
Pin Denitions (JF1)
Pins Denition
19 Control
20 Ground
