Supermicro Superserver - Page 55

55
Chapter 4: Motherboard Connections
VRM
Jumper Settings
Jumper Setting Denition
Pins 1-2 BMC (Normal)
Pins 2-3 PCH
I
2
C Bus for VRM
Jumpers JVRM1 and JVRM2 allow the BMC or the PCH to access CPU and memory VRM

Manufacturing Mode



Manufacturing Mode Select
Jumper Settings
Jumper Setting Denition
Pins 1-2 Normal (Default)
Pins 2-3 Manufacturing Mode
Management Engine (ME) Recovery
            
allocation for essential system operation only in order to maintain normal power operation
and management. In the single operation mode, online upgrade will be available via Recovery

ME Recovery Mode
Jumper Settings
Jumper Setting Denition
Pins 1-2 Normal
Pins 2-3 ME Recovery
