1-6
X7SLM/X7SLM+ User’s Manual
Motherboard Features
CPU
Single Intel® Core™ 2 Duo/Pentium dual-core/Pentium D/Pentium 4/Celeron •
dual-core/Celeron/Celeron D Processor with a system bus speed of up to 800
MHz and the CPU voltage of up to 65W.
Notes: For system stability, please do not use a processor with the volt-
age higher than 65W.
Features supported by the Core™ 2 Duo CPU:
Dual-core CPU (support up to 65W)•
FSB Dynamic Bus Inversion (DBI)•
Intel® Smart Memory Access•
Intel® Dynamic Power Coordination •
Memory
Supports unbuffered Non-ECC DDR2 up to 2 GB/s (DDR2 667/533/400) for •
dual-channel mode.
Chipset
Intel® 945GC GMCH (North Bridge), ICH7 (South Bridge) •
Supports Intel Graphics Media Accelerator GMA 950•
Expansion Slots
One (1) PCI-Express x8 slot (Slot 6)•
One (1) 32-bit PCI 33MHz slot (Slot 5) •
BIOS
8 Mb AMI BIOS•
®
, SPI Flash BIOS
DMI 2.3, PCI 2.2, ACPI 1.0/2.0/3.0, Hardware BIOS virus protection, SMBIOS •
2.5, and Plug and Play (PnP)
PC Health Monitoring
Onboard voltage monitors for CPU Cores, Memory Voltage, Chipset Voltage, •
+3.3V, +3.3V standby, +5V, +5V Standby, +12V and VBat
Fan status monitor with rmware 4-pin (Pulse Width Modulation) •
Low noise fan speed control•
CPU 3-Phase-switching voltage regulator•
SuperoDoctor III, Watch Dog, NMI•
Power-up mode control for recovery from AC power loss•
I•
2
C temperature sensing logic
CPU/System overheat LED and control•
