Chapter 2: Installation
2-7
X7SLM/X7SLM+
I/OPortLocationsandDenitions
2-5 Connectors/IO Ports
The I/O ports are color coded in conformance with the PC 99 specication. See the
gure below for the colors and locations of the various I/O ports.
Back Panel Connectors and IO Ports
Back Panel Connectors
1. Keyboard (Purple)
2. PS/2 Mouse (Green)
3. USB Port 1
4. USB Port 2
5. COM Port 1 (Green)
6. VGA (Blue)
7. LAN Port 1
8. LAN Port 2
2
4
7
1
3
5
6
8
