Chapter 1: Introduction
1-3
Audio
One (1) High Denition Audio 7.1 channel connector
supported by Realtek ALC1150 on the back panel
One (1) Front Panel Audio Header
One (1) S/PDIF Out on the rear side of the chassis
Super I/O
Nuvoton NCT6792D-B
BIOS
128 Mb AMI BIOS
®
SPI Flash BIOS
Plug and Play (PnP), DMI 2.8, PCI 2.3, ACPI
1.0/2.0/3.0, and USB Keyboard
Power
Configuration
ACPI/ASPM Power Management
Main Switch Override Mechanism
Internal/External Modem Ring-On
Power-on mode for AC power recovery
Health
Monitoring
CPU Monitoring
Onboard monitors: CPU core, +3.3V, +5V, 12V, +5V
Stby, VBAT, HT, Memory PCH Temperature, System
Temperature, and CPU Temperature
CPU 5+2 phase switching voltage regulator
CPU/System overheat LED and control
CPU Thermal Trip support
Thermal Monitor support
Fan Control
Fan status monitoring with 4-pin fan speed control
Low noise fan speed control
System
Management
PECI (Platform Environment Conguration Interface)
2.0 support
System resource alert via SuperDoctor
®
5
SuperDoctor 5
Chassis Intrusion header and detection
CD Utilities
BIOS ash upgrade utility
Drivers and software for Intel® Z270 Express chipset
tilities
Other
ROHS 6/6 (Full Compliance, Lead Free)
Dimensions
ATX form factor (12.0" x 9.6") (304.8 mm x 243.84
mm)
