Supermicro C7Z270-CG-L Motherboard User’s Manual
1-3 Motherboard Features
CPU
Single 6th and 7th Generation Intel® Core
TM
i7/i5/
i3, Pentium®/Celeron® processor in an LGA1151 type
socket with up to 120Watt TDP
Memory
Four (4) slots support up to 64GB of unbuffered, non-
ECC, 2133MHz to 2800+MHz(OC) DDR4 memory*
Dual-channel memory
DIMM sizes
UDIMM 4GB, 8GB, 16GB
Chipset
Intel® Z270 Express
Expansion Slots
Three (3) PCH PCI-E 3.0 X1 slot
One (1) PCH PCI-E 3.0 X4 slot
Two (2) CPU PCI-E 3.0 X16 slots (X16/NA or X8/X8)
Two (2) NVMe PCI-E X4 M.2 slots
Network
Connections
One (1) Gigabit Ethernet Controller
One (1) RJ-45 rear I/O panel connector with Link and
Activity LEDs
I/O Devices Hard Drive Connections
SATA 3.0 (6Gb/s) Six (6) I-SATA 0~5, via Intel Z270
RAID 0, 1, 5, 10
USB Devices
Four (4) USB 3.0, two (2) USB 3.1, and two (2) USB
2.0 ports on the rear I/O panel
Four (4) Front-Accessible USB 2.0 ports on two head-
ers and Two (2) Front Accessible USB 3.0 ports on one
header.
Graphics
One (1) VESA DisplayPort
One (1) DVI-D Port
One (1) HDMI 1.4 Port
Supports nVidia® SLi Technology via onboard PCI-E
3.0 x16 solts
Keyboard/Mouse
One shared PS/2 Keyboard/Mouse port on the I/O
backpanel
Other I/O Ports
One (1) TPM 2.0 Header
One (1) Serial Port header (COM1)

Supero C7Z270-CG-L Specifications

General

Brand	Supero
Model	C7Z270-CG-L
Category	Motherboard
Language	English
