Supero X10SL7-F User Manual

1-6
X10SL7-F User’s Manual
Motherboard Features
CPU Single Intel® Xeon E3-1200 v3 or 4th Generation Core i3
processor in an LGA1150 socket.
Memory Four (4) SDRAM slots support up to 32 GB of DDR3 Unbuf-
fered, ECC 1600/1333 MHz memory
Dual-channel memory
DIMM sizes
UDIMM 1 GB, 2 GB, 4GB, and 8GB
Chipset Intel® C222 Express
Expansion Slots One (1) PCI Express 2.0 x4 in x8 slot (PCH Slot 5)
One (1) PCI Express 3.0 x8 in x16 slot (CPU Slot 6)
Two (2) RJ-45 rear I/O panel connectors with Link and
Activity LEDs
I/O Devices SATA/SAS Connections
SATA 3.0 (6Gb/s) Two (2) I-SATA 0/1, via Intel C222
RAID 0, 1
SATA 2.0 (3Gb/s) Four (4) I-SATA 2~5, via Intel C222
RAID 0, 1, 5, 10 (MS Windows
®
)
RAID 0, 1, 10 (Linux)
SAS Eight (8) L-SAS 0-7 supported by the
LSI 2308 SAS Controller
USB Devices
Four (4) USB 2.0 ports on the rear I/O panel (USB 2/3,
4/5),
Two (2) USB 3.0 headers for USB 3.0 support (USB 0,
USB 1) (USB 0 is a Type A connector)
Two (2) Front Accessible USB 2.0 ports on one header
(USB 8/9)
Serial (COM) Ports
COM Port (COM1), COM Header (COM2)
Graphics Controller
AST 2400 Graphics Controller
Super I/O
Nuvoton NCT6776D
BIOS 128 Mb AMI BIOS
®
SPI Flash BIOS
Play and Plug (PnP), DMI 2.3, PCI 2.3, ACPI 1.0/2.0/3.0,
USB Keyboard and SMBIOS 2.5
