Supero X9DRH-7F User Manual

2-6
X9DRH-7F/-iF/-iF-NV/-7TF/-iTF Motherboard User’s Manual
WARNING!
OPEN 1st
WARNING!
OPEN 1st
WARNING!
OPEN 1st
WARNING!
Gently push
down to pop the
load plate open.
2. Press the second load lever labeled 'Close 1st' to release the load plate that
covers the CPU socket from its locking position.
3. With the lever labeled 'Close 1st' fully retracted, gently push down on the
'Open 1st' lever to open the load plate. Lift the load plate to open it com-
pletely.
1
2
Press down on Load the
Lever labeled 'Close 1st'
1
Pull lever away from
the socket
2
