Supero X9DRH-7F User Manual

2-8
X9DRH-7F/-iF/-iF-NV/-7TF/-iTF Motherboard User’s Manual
OPEN 1st
OPEN 1st
4. With the CPU inside the socket, inspect the four corners of the CPU to make
sure that the CPU is properly installed.
5. Close the load plate with the CPU inside the socket. Lock the lever labeled
'Close 1st' rst, then lock the lever labeled 'Open 1st' second. Use your
thumb to gently push the load levers down to the lever locks.
OPEN 1st
Lever Lock
Lever Lock
Push down and
lock the lever
labeled 'Open 1st'
Push down and lock the
level labeled 'Close 1st'.
Gently close
the load plate.
1 2
3
4
