1-6
X9SAE Motherboard Series User’s Manual
X9SAE Motherboard Series Headers/Connectors
Connector Description
AUDIO FP Front Panel Audio Header
JAUDIO High-Denition Audio Connectors (on the I/O back panel)
BAT1, SPK1 Onboard Battery, Internal Speaker/Buzzer
COM1, COM2 COM1 Port (Back Panel), COM2 Serial Port Header
FAN1~FAN4, FANA System/CPU Fan Headers (FAN1: CPU Fan, FANA: I/O Cards)
JD1 Speaker/buzzer (Pins 1-2: Buzzer, Pins 1~4: External Speaker)
JF1 Front Panel Control Header
JLED Power LED Indicator Header
JPW1 24-pin ATX Main Power Connector (Required)
JPW2 +12V 8-pin CPU power Connector (Required)
JPW3 +12V 4-pin Auxilliary power Connector
KB/MS Keyboard/Mouse Connectors
LAN1/LAN2 Gigabit (RJ45) Ports (LAN1/2)
S/PDIF IN, S/PDIF OUT SPDIF (Sony/Philips Digital Interface) In/Out Headers
JSD1 SATA DOM (Device_On_Module) Power Connector
SLOT1 PCI 33MHz Slot
SLOT2 PCI-E 2.0 x4 (in x8) Slot
SLOT3, SLOT5 PCI-E 2.0 x1 Slot
SLOT4 X9SAE-V: PCI-E 3.0 x8 (in x16)
SLOT6 PCI-E 3.0 x16 Slot (X9SAE-V: PCI-E 3.0 x8 (in x16) Slot)
SLOT7 PCI-E 2.0 x4 Slot
HDMI1, HDMI2 Backpanel HDMI Ports
JL1 Chassis Intrusion Header
JSTBY Legacy Wake on LAN Header
JTPM1 TPM (Trusted Platform Module) 1.2 Header
I-SATA0 / I-SATA1 Serial ATA (SATA 3.0) Ports 0/1 (6Gb/sec)
I-SATA 2~I-SATA5 Serial ATA (SATA 2.0) Ports 2~5 (3Gb/sec)
USB 8/9, 10/13 Backpanel USB 2.0 8/9, 10/13
USB 2/3 Backpanel USB 2.0 2/3 (USB 3.0 3/4)
USB 0/1 Front Panel Accessible USB 2.0 Headers 0/1 (USB 3.0 1/2)
USB 4/5, 11/12 Front Panel Accessible USB 2.0 Headers 4/5, 11/12
T-SGPIO1, T-SGPIO2 Serial General Purpose I/O Headers (for SATA)
VGA Backpanel VGA Port
