Chapter 1: Introduction
1-7
Motherboard Features
CPU Intel® Xeon® E3-1200 v2 series, Xeon E3-1200 series,
Pentium®, and Celeron® processor in an LGA 1155 socket
Memory Four (4) slots support up to 32 GB of unbuffered, ECC
DDR3 UDIMM memory (1600/1333/1066 MHz)
Supports dual-channel memory bus
DIMM sizes
UDIMM 2 GB, 4GB, and 8GB
Chipset Intel® C216
Expansion Slots Two (2) PCI Express 2.0 x1 slot
One (1) PCI Express 2.0 x4 slot
One (1) PCI Express 2.0 x4 (in x8) slot
One (1) PCI Express 3.0 x16 slot (X9SAE only)
Two (2) PCI Express 3.0 x8 in x 16 slot (X9SAE-V only)
One (1) PCI 33 MHz slots (5 Volts)
Network Connections Two (2) Gigabit Ethernet Controllers:
LAN1: Intel 82579LM
LAN2: Intel 82574L
Two (2) RJ-45 Rear I/O Panel Connectors with Link and
Activity LEDs
I/O Devices SATA Connections
SATA 3.0 (6Gb/s) Two (2) SATA 0~1
RAID 0, 1
SATA 2.0 (3Gb/s) Four (4) I-SATA 2~5
RAID 0, 1, 5, 10 (MS Windows
®
)
RAID 0, 1, 10 (Linux)
Disk-on-Module (DOM) header
USB Devices
Four (4) USB 2.0 ports and two (2) USB 3.0 ports on the
rear I/O panel
Six (6) Front Accessible USB 2.0 ports on three headers,
and two (2) Front Accessible USB 3.0 ports on one header
Keyboard/Mouse
One shared PS/2 Keyboard/Mouse port on the I/O
backpanel
Serial (COM) Ports
One (1) Front accessible Serial Port header (COM2)
One (1) Serial Port on the back panel (COM1)
