Supero X9SAE - Page 20

1-8
X9SAE Motherboard Series User’s Manual
Audio
Five (5) Female Mini Jacks for High Denition Audio on
the Back Panel
Front Panel Audio Header
One (1) S/PDIF Optical Out on the back panel
S/PDIF In and S/PDIF Out Headers
Video
One VGA (D-Sub), two (2) HDMI ports on the back panel
nVidia® SLi® and AMD® Crossre™ X support
BIOS 128 Mb AMI BIOS
®
SPI Flash BIOS
Play and Plug (PnP0, DMI 2.3, PCI 2.2, ACPI 1.0/2.0, USB
Keyboard and SMBIOS 2.3
Power Conguration ACPI/APM Power Management
Main Switch Override Mechanism
Keyboard Wake-up from Soft-Off
Power-on mode for AC power recovery
PC Health Monitoring CPU Monitoring
Onboard voltage monitors for 1.8V, +3.3V, +5V, +/-12V,
+3.3V Stdby, +5V Stdby, VBAT, HT, Memory, Chipset
CPU 4+2 phase switching voltage regulator
CPU/System overheat LED
CPU Thermal Trip support
Thermal Monitor 2 (TM2) support
Fan Control
Fan status monitoring with rmware 4-pin (Pulse Width
Modulation) fan speed control
Low noise fan speed control
System Management PECI (Platform Environment Conguration Interface) 2.0
support
System resource alert via SuperDoctor
®
III
SuperDoctor III, Watch Dog, NMI
Chassis Intrusion header and detection, TPM 1.2 header
CD Utilities BIOS ash upgrade utility
Drivers and software for Intel® C216 chipset utilities
Other ROHS 6/6 (Full Compliance, Lead Free)
Dimensions ATX form factor (12.0" x 9.6")
