Chapter 2: Installation
2-21
2-6
Jumper Settings
Explanation of Jumpers
T
o
modify
the
operation
of
the
motherboard,
jumpers
can
be
used
to
choose
between
optional
settings.
Jumpers
create
shorts
between
two
pins
to
change
the
function
of
the
connector
.
Pin
1
is
identied
with
a
square
solder
pad
on
the
printed
circuit
board.
Note:
On two-pin
jumpers, "Closed"
means the
jumper
is on
and "Open"
means
the
jumper
is
of
f
the
pins.
