- 29 -
>> backside safe chamfering(middle) >> backside safe chamfering(large)
8.Lens processing mode：
>>Optical Center mode >>Geometric center mode
9.Polishing choice：
>>polish >>not polish
10.Others：
>>unlock the lens >>start to proceeding >>stop proceeding >>proceeding size
>> retouch
11.Clamping pressure：
>>(level one)Fragile lens >>(level two)normal lens >>(level three)slippery lens
>>return
3.3 LENS PROCESSING
3.3.1 CLAMP/REMOVE THE LENSES
> Clamp the lens into grinding window
After all the grinding data is entered, clamp the lens；
Each kind of lens should choose appropriate clamp
19 mm diameter adaptors
25 mm diameter adaptors
The warning information will display if the processed lenses needs special clamp,as the following
figure：
19mm small clamp
25mm big clamp
