- 42 -

5.4 REPLACE LENS FEELER

> Check the lens scanner regularly，change the it once the wear or damage is found（Or replace

every 3,000 lenses）.

>After the lens feeler is replaced, the lens feeler position needs to be recalibrated.

The calibration probe procedure is as follows：

>> >>

#1 Enter the

#2 Enter setup

interface

#3 Enter setup

interface

#4 Take out tool

#5 Input correction tool

thickness value

士

#6 Replace the 25mm clamp

#7 Load calibration tool

#8 Start calibrating

#9 The machine starts the calibration procedure, saves the calibration parameters automatically,

and then takes out the calibration tool when the calibration is completed.

25mm 大夹头

Dismountable lens feeler

Remove the screws and replace the lens feeler
