SureShot IntelliShot AC230PC User Manual

21
CLEANING:Remove&CleantheDispensingValveAssembly–SelfServeDispensers
NOTES: Prepareacontainerofwarm,soapywaterbeforeyou
takethevalveapartforcleaning.
Becarefulnottodislodgethecableduringcleaning.
1. TurnthepowertothedispenserOFF.
2. Drainproducttanksandremoveemptytanks.
3. Openthedoortotherefrigeratedproductcompartment.
4. Removethecatchtray(ifapplicable)byliftingitupandoff.
5. Removethe4panheadscrews(+)thatsecurethefrontsplash
panel/valvecoverinplaceandcarefullyremovethefrontsplash
panel/valvecover.Itislocatedbelowthewhiteplasticvalvesthat
holdtheproducttubes.Itisheldinplaceby4Phillipsheadscrews
(+).
Thoroughlywashthesplashpanel.
6. Openthevalvedoor:unscrewtheblackknobinacounterclockwise
motion.
7. RemovethePhillipsheadscrewwhichretainsthealuminuminsert.
Donotmisplacethescrew. Wipetheinsertandscrewclean.
8. Removethe2Phillipsheadscrewsattheuppercornersofthevalve
block. Donotmisplacethescrews.
9. Removethewhitevalvebody.Holdthevalvecarefullywithonehand
sothatthethermistorwirewillnotbebrokenordamaged.Thesteel
handlecomesoffwiththevalvebody.
NOTE: Thevalvebodycanonlybemovedthelengthofthe
the rmistorwire,whichislocatedintheleftvalve.
10. Removetheplungertipandspring.Wash,rinse,sanitize,andairdry
the plungertipandspring.
11. Wipethespringcupclean.
12. Washthehandle,plungertipandspringinwarm,soapywater.
Rinsewithclearwater. Drythoroughly.
13. Cleanthewhiteplasticsectionsofthevalveblock,usingasmall
brushwithwarm,soapywater. Drythoroughly.
14. Cleanthevalvedoorfront,valvedoorback,andinsert.
15. Putthespringandplungerbacktogethersothatyoucanreassemble
thevalvebody.
16. Alignthevalvebodywiththeplunger.Movebackintoplace.
17. Replacethe2Phillipsheadscrews.Tightenuntilsnug.
18. ReplacethePhillipsheadscrewatthetopofthemetalvalveinsert.
Thisscrewmustfitsnuglytoensureproperoperationofthe
refrigerationsystem. Donotovertightenthescrew.
19. Closethevalvedoor.
20. Securethedoorbytighteningtheknobscrewinaclockwisemotion
untilthedoorissnug. Donotovertightenthescrew.
21. Reinstallthe4Phillipsheadscrewstosecurethefrontpanelin
place.
22. Wipetheproductcompartmentclean.
23. Closetherefrigeratedproductcompartmentdoor.
24. Loadnewproductanddispense.
Step5
Step7
Step8
Step9
