SureShot IntelliShot AC230PC User Manual

24
REFRIGERATIONSYSTEMANDTEMPERATUREADJUSTMENT
REFRIGERATIONSYSTEM
· Therefrigerationsystemisahermeticallysealedsystemwhichusesenvironmentally
friendlyR134Arefrigerant.
· Ifrechargingofthesystemisrequired,therefrigerationtechnicianshouldrefertothe
SureShot DispensingSystems®MachineIdentificationLabellocatedontheleftsideof
thedispenserfordetailsonthequantityofrefrigerantused.
· Thecondenserislocatedattherearofthedispenserbehindthebackpanel.
· Theevaporatorisincorporatedwithinthestainlesssteelwallsoftherefrigeratedproduct
compartment,i.e.coldwallevaporationsystem.
· Thecompressorislocatedbelowtherefrigeratedproductcompartmentandisaccessible
throughthebackpanel.
RefrigerationSystem
Refrigerated
Compar tment
Condenser
Fan
Filter/Dryer
Compressor
CapillaryTube
