SureShot IntelliShot AC230PC User Manual

25
TEMP ERATURECONTROLADJUSTMENT
EachSureShotDispensingSystems®dispenserispresetatourfactorytomeetyouroperating
standards.Thesesettingsshouldnotrequireadjustment.
Thetemperatureintherefrigeratedproductcompartmentissetatourfactoryfornormalusein
the NorthAmericanfoodserviceindustry.Thetemperatureissettomaintaintheproductwithin
the  range of 35ºF to 40ºF (1.6ºC to 4.4ºC).  The temperature is controlled by an adjustable
the rmostat.Theadjustmentthermostatislocatedonthecircuitboard.(Seebelow.)
1. Removethe4screwsthatsecurethefrontsplash
panel/valvecoverinplaceandcarefullyremovethe
frontpanelcover.Itislocatedbelowthewhiteplastic
valvesthatholdtheproducttubes.
2. Whenthiscoverisremoved,locatethecircuitboard
thathaselectroniccomponentsonit.AredLED
lightshouldbe(ON)indicatingthatthereispower
suppliedtotheboard.
3. Identifywhichcircuitboardisinstalledinthe
dispenser. Thecircuitboardisoneoftwostyles,a
variationoftheB16designorthenewerC01008
design.
B16 C01008
LocatetheTemperatureAdjustmentPot(R36),
whichisonthebottomofthecircuitboard. It
is a b lue plastic square, approximately ½”
square. It has a white circular center with a
slot. From the factory this adjustment is
normallysetwiththeslotvertical(at12and6
o’clockifyou weretocompareittohandsona
clock).
Locate the UP (SW1) and DOWN (SW2)
adjustmentbuttons,whichareonthebottomof
the  circuit board.  Press either the UP or
DOWNbuttonandthecircuitboarddisplaywill
show the current refrigeration setting. From
thefactory,thissettingisnormallybetween04
and09.Fullrangeof adjustmentis00(OFF)
to12.
